Presentation

Description

SECURITHERM thermostatic basin mixer
Ref. H9600

SECURITHERM thermostatic sequential basin mixer, deck-mounted H. 85mm L. 120mm, without pop-up waste.
Anti-scalding failsafe: shuts off immediately if cold water supply fails.
Securitouch thermal insulation prevents burns.
No non-return valves on the inlets.
Straight spout with hygienic flow straightener for no impurity retention and thermal shock-resistant.
Scale-resistant thermostatic sequential cartridge for single control of flow rate and temperature.
Cold water temperature can be adjusted up to 40°C with temperature limiter set at 40°C and thermal and chemical shocks are possible.
Body and spout with smooth interiors and low water volume.
Flow rate limited to 7 lpm at 3 bar.
No manual contact thanks to Hygiene control lever L. 146mm.
Supplied with braided stainless steel flexibles made from PEX F3/8" with chrome-plated brass stopcocks.
Reinforced fixing via 2 stainless steel rods.
10-year warranty.

Advantages

  • Bacterial proliferation control

  • SECURITHERM : Optimal anti-scalding safety

  • Opens and closes via single control lever

  • No non-return valves

Characteristics

Technical features

SECURITHERM thermostatic basin mixer
Ref. H9600

Connector M1/2"
Technology SECURITHERM single control, Securitouch
Drop height 85mm
Spout length 120mm
Flow rate 7 lpm
Temperature limiter 40°C
Finish Chrome-plated brass
Standards and certifications TMV3 WRAS HKWSD ACS
Warranty 10-Year
