Page 73 - Stainless_Steel_Sanitary_Ware

Drinking fountains /

SD drinking fountains ILHA and ILHA JR drinking fountains
Wall-mounted Floor-standing

• Wall-mounted drinking fountain.
• Bacteriostatic 304 stainless steel. Stainless steel thickness: 1.2mm.
• Rounded edges prevent injury.
• Models with WRAS approved bubbler tap: chrome-plated,
instant shut-off and adjustable flow rate, inlet M⅜".
• Models with WRAS approved swan neck tap for filling water bottles:
chrome-plated brass body and stainless steel spout, instant shut-off
with adjustable flow rate, M⅜" connection.
• Flat perforated waste, without screws: easy to clean and vandal-resistant.
• Waste outlet 11/4".
• Supplied with fixing elements.
• Weight : 2.4kg to 3kg depending on the model.
• 30-year warranty.
• Floor-standing drinking fountain.
• Bacteriostatic 304 stainless steel. Stainless steel thickness: 0.8mm.
• Available in two different heights: 915mm and 800mm for children.
• Supplied with a WRAS approved bubbler tap:
chrome-plated, instant shut-off and adjustable flow rate, inlet M⅜".
• Flat perforated waste, without screws: easy to clean and vandal-resistant.
• Recessed vertical water outlet. Waste outlet 11/4".
• Weight: 9kg for the 800mm model; 9.6kg for the 915mm model.
• 30-year warranty.

35 35 35
35
150 150 90 90 150 150 90 90
250
250 250
250
320 320 320 320 915
800
PROFESSIONAL EQUIPMENT
320 320
320
320
330 330

Ø 320 Ø 320
35 35
150 90 150 90
250 250
180800 180820 180110 180100
320 320
Wall-mounted SD drinking fountains - Polished satin 304 stainless steel
320
320
With bubbler tap 180800 Floor-standing ILHA and ILHA JR drinking fountains with integrated bubbler tap
With swan neck tap 180810 Polished satin 304 stainless steel - Height 915mm 180100
With bubbler and swan neck taps 180820 Polished satin 304 stainless steel - Height 800mm 180110
: dispatch within 4 weeks : stock item

Professional equipment 71
