/ TEMPOMIX time flow shower panels

• Exceptional water savings: 80%
• Comfort: temperature selection directly on the single control mixer, soft-touch operation, rain-effect spray
• Vandal-resistant: aluminium panel, concealed fixings, solid brass shower head and shower valve

TEMPOMIX aluminium
Time flow shower panel
• Anodised aluminium shower panel for wall-mounted,
exposed installation.
• TEMPOMIX mixer with adjustable maximum temperature limiter.
• Soft-touch operation.
• Time flow ~30 seconds.
• Flow rate 6 lpm at 3 bar, comfortable rain-effect spray.
• Chrome-plated, tamperproof, ROUND shower head
with automatic flow rate regulation or sliding handset
on a chrome-plated rail with flexible hose.
• M½" connections.
• Concealed fixings.
• Filters and non-return valves.
• Suitable for people with reduced mobility.
• 30-year warranty.

34
210 34 Ø15
210
80 30°
1/2" 80 1/2"
80 80
170-190

1050 945 1050

790300 79035015

TEMPOMIX time flow shower panel with fixed shower head
Top inlet via in-line stopcocks
M½" 790300
Ø 15mm for compression fittings 79030015
Concealed inlet via flexibles
M½" 790310
TEMPOMIX time flow shower panel with sliding handset
Top inlet via in-line stopcocks
M½" 790350
Ø 15mm for compression fittings 79035015
We recommend installing a TMV (see page 143) and a floor trap (see page 131)
Option: extensions for shower panels (see page 136)
