TEMPOMIX / TEMPOSTOP time flow basin controls /

                       •  Exceptional water savings: 85%
                       •  Vandal-resistant: cross wall installation, concealed fixings, anti-blocking system (AB)




               TEMPOMIX                                             TEMPOSTOP
               Cross wall time flow basin mixer                      Cross wall time flow basin tap























               • Soft-touch operation.                              • Time flow ~7 seconds.
               • Temperature control and operation via the push-button.  • Flow rate pre-set at 3 lpm at 3 bar, can be adjusted from 1.4 - 6 lpm.
               • Time flow ~7 seconds.                               • Tamperproof scale-resistant flow straightener.
               • Flow rate pre-set at 3 lpm at 3 bar, can be adjusted from 1.4 - 6 lpm.  • Tamperproof cross wall control ≤ 220mm.
               • Tamperproof scale-resistant flow straightener.      • Chrome-plated brass fixed tamperproof cross wall spout ≤ 230mm.
               • Chrome-plated brass body M¾".                      • Anti-rotating pin and back nut.
               • Chrome-plated metal push-button.                   • AB anti-blocking system: water only flows when push-button is released.
               • Filters and non-return valves.                     • Available with 1 or 2 controls.
               • Adjustable maximum temperature limiter.            • Threaded rods can be cut to size.
               • Tamperproof cross wall control ≤ 220mm.            • 30-year warranty.
               • Tamperproof fixed cross wall spout ≤ 230mm.
               • System for fixing to the wall via anti-rotating pin,
                back-nut and connection clamp.
               • Threaded rods can be cut to size.
               • 30-year warranty.


                                              Ø 70                              1/2"  Ø 21  200 max  4
                             3/4"
                                        Ø 21
                                                                               60                    Ø 50
                            45
                              30  120 min  220 max  55                         1/2"  120 min
                                                                                  1/2"  Ø 21
                                              Ø 50
                                  1/2"  Ø 21                                        1/2"  Ø 21
                                                                                                                             SECURE SECTOR
                                         230 max  75                                       230 max  75

                                      795209                                              748110




                                            1/2"                                               1/2"


                                      826315                                             826315


                                                                    TEMPOSTOP cross wall basin tap
                                                                    1 control                                   748110
               TEMPOMIX cross wall basin mixer
                                                                    2 controls                                 748210
               TEMPOMIX cross wall                        795209
                                                                    Back-nut F½" with 3 screws (reinforcing clamp behind the wall)   826315
               Back nut F½" with 3 screws (reinforcing clamp behind the wall)  826315
                                                                    We recommend installing a TMV (see page 143)
               Alternative cross wall lengths (up to 400mm, min. 200 units) available on request  Alternative cross wall lengths available on request
