TEMPOFLUX 1 and 3 time flow direct flush systems /
• Efficiency and water savings: direct flush reduces the risk of leaks, powerful flush is instantly available
• Vandal-resistant: cross wall installation, concealed fixings
• Hygiene: no cistern: no water stagnation (reduces bacterial development)
• Comfort: soft-touch operation
TEMPOFLUX 3 AB TEMPOFLUX 1
Cross wall time flow flush valve Cross wall time flow flush valve
• Flush system without cistern: directly connected to pipework. • Flush system without cistern: directly connected to pipework.
• For walls ≤ 200mm. • For walls ≤ 200mm.
• Soft-touch operation. • Time flow ~7 seconds.
• AB anti-blocking system: flush only takes place once the push-button • Vacuum breaker.
is released. • In-line stopcock and flow rate/flush volume adjuster.
• Time flow ~7 seconds. • Chrome-plated metal body.
• Vacuum breaker. • Shock-resistant mechanism.
• Stopcock and volume/flow rate adjustment, activation unit • In-line inlet M¾".
and cartridge are all integrated and accessible via the service duct. • Connection washer Ø 32/55mm.
• Chrome-plated metal push-button. • Threaded rod can be cut to size.
• Shock-resistant mechanism. • Supply pipe diameter: Ø 20mm minimum internal pipe diameter
• In-line inlet M¾". is required at all points (connectors included).
• Complies with European standard EN 12541 (class II acoustic level). • Base flow rate: 1 L/sec. at 1 bar dynamic pressure.
• Threaded rod can be cut to size. • Available with or without PVC flush tube Ø 32mm.
• Supply pipe diameter: Ø 20mm minimum internal pipe diameter • Compatible with rain water.
is required at all points (connectors included). • 30-year warranty. 162 200 max
• Base flow rate: 1 L/sec. at 1 bar dynamic pressure. 36 3/4"
• Available with or without PVC flush tube. 4
• Compatible with rain water. 63 Ø 50
• Suitable for rimless WC pans and for people with reduced mobility. Ø 21
• 30-year warranty.
SECURE SECTOR
880 max
136 200 max
3/4" Ø 32
Ø 50
147 Ø 21
Ø 32
Ø 55
763256 761210
435 max
TEMPOFLUX 1 WC cross wall
TEMPOFLUX 3 AB WC cross wall With flush tube 761210
With flush tube 763266 Without flush tube 761110
Without flush tube 763256 Alternative cross wall lengths available on request
