Time flow basin controls TEMPOSOFT 2 /

• Water savings: 85%
• Vandal-resistant: solid brass, reinforced fixings, streamlined design
• Comfort: temperature selection via side temperature lever on mixers, soft-touch operation

TEMPOSOFT MIX 2 TEMPOSOFT 2
Deck-mounted time flow basin mixer with soft-touch operation Time flow basin tap with soft-touch
BASINS

TEMPOSOFT 2
Wall-mounted time flow tap with soft-touch

• Soft-touch operation.
• Time flow ~7 seconds.
• Flow rate pre-set at 3 lpm at 3 bar, can be adjusted from 1.4 - 6 lpm.
• Tamperproof scale-resistant flow straightener.
• Chrome-plated solid brass body.
• PEX flexibles with filters and non-return valves.
• Fixing reinforced by 2 stainless steel rods.
• Side temperature control lever with adjustable maximum temperature limiter
on mixers.
• Suitable for people with reduced mobility.
• 30-year warranty.
• Chrome-plated solid brass body M½".
• Supplied with blue and red markers.

50
Standard lever Long lever
Ø 48

Ø 48 1/2"
85
75
85 85 110 15
1/2"
100 30 max 1/2"
40 max 40 max 740300 741500 822741
100 100
400 355 TEMPOSOFT 2 deck-mounted tap

Fixing reinforced by back-nut 740300
with 3 stainless steel screws
3/8" 3/8"
Fixing with back-nut 740500
Fixing with back-nut - DZR LEAD FREE 740510AS
742500 742510LH TEMPOSOFT 2 wall-mounted tap
L. 110mm 741500
L. 110mm - DZR LEAD FREE 741510AS
Ø15mm for
F⅜" without L. 150mm 741550
F⅜" comp. fittings
stopcock
(UK/Ireland) L. 150mm with back nut 741555
TEMPOSOFT MIX 2 deck-mounted mixer 742500 742510 74250015 50mm chrome-plated brass extension 822741
For long lever, please add "LH" after the reference We recommend installing a TMV (see page 143)
Basins 61
