TEMPOMIX 3 time flow basin controls /

                       •  Exceptional water savings: 85%
                       •  Comfort: temperature selection directly via the single control mixer, soft touch operation
                       •  Vandal-resistant: chrome-plated stainless steel body, reinforced concealed fixings



               TEMPOMIX 3                                           TEMPOMIX 3
               Time flow basin mixer with soft-touch operation       Time flow basin mixer with soft-touch operation
                                                                                                                             BASINS
                NEW                                                  NEW




















               • H. 170mm for semi-recessed basins.                 • H. 250mm for deck-mounting.
               • Soft-touch operation.                              • Soft-touch operation.
               • Temperature control and operation via the push-button.  • Temperature control and operation via the push-button.
               • Time flow ~7 seconds.                               • Time flow ~7 seconds.
               • Flow rate pre-set at 3 lpm at 3 bar, can be adjusted from 1.4 - 6 lpm.  • Flow rate pre-set at 3 lpm at 3 bar, can be adjusted from 1.4 - 6 lpm.
               • Tamperproof, scale-resistant flow straightener.     • Tamperproof, scale-resistant flow straightener.
               • Chrome-plated stainless steel body.                • Chrome-plated stainless steel body.
               • PEX flexibles F⅜" with filters and non-return valves.  • PEX flexibles F⅜" with filters and non-return valves.
               • Fixing reinforced by back-nut.                     • Fixing reinforced by back-nut.
               • Adjustable maximum temperature limiter.            • Adjustable maximum temperature limiter.
               • Suitable for people with reduced mobility.         • Suitable for people with reduced mobility.
               • 30-year warranty.                                  • 30-year warranty.










                                                                                      255
                                 170                                                        185       160
                                      175       85
                                       Ø52                                                  Ø52
                                       Ø34                                                  Ø34
                                               55 max  500                                          55 max  360
                                        3/8"
                                                                                              3/8"
                                      794110                                               794120








                                                                                                  Awards:
               Product currently under development.                 Product currently under development.
               TEMPOMIX 3 deck-mounted mixer                        TEMPOMIX 3 deck-mounted mixer
               TEMPOMIX 3 mixer height 170mm              794110    TEMPOMIX 3 mixer height 250mm              794120
               M⅜" connection Ø 15mm for compression fittings (2 pieces)  803815.2P  M⅜"connection Ø 15mm for compression fittings (2 pieces)  803815.2P


                                                                                                             Basins  53
