/ SECURITHERM sequential thermostatic mixers

SECURITHERM Securitouch shower mixer
Sequential thermostatic mixer, with no non-return valves

• Sequential: opens and closes with cold water (see page 112).
• No risk of cross flow between hot and cold water.
No non-return valves on the inlets.
• Anti-scalding failsafe: automatic shut-off if cold water supply fails.
• Prevents cold showers: automatic shut-off if hot water supply fails.
• Securitouch thermal insulation prevents burns.
• Scale-resistant sequential thermostatic cartridge.
• Temperature control: cold water up to 39°C.
• Temperature limiter set at 39°C.
• For ref.s H963015 and H964015: tested without water to comply
with NHS requirements (UK). No pre-set temperature. Smooth interior = very little biofilm
Thermal insulation on HW side
• Thermal shocks are possible. No non-return valves
• Body with smooth interior and low water volume
(reduces bacterial development).
• Flow rate regulated at 9 lpm.
• Hygiene control lever L. 100mm.
• Top or bottom outlet options.
• Supplied with 2 offset STOP/CHECK connectors M½" M¾" (ref. 855755.2P),
2 in-line STOP/CHECK connectors M½" M¾" (ref. 855755UK.2P)
or 2 offset standard connectors M½" M¾" (ref. 856794.2P) (see page 140).
• Suitable for people with reduced mobility.
• 30-year warranty.

1/2" 3-35 48,5
SECURITHERM Securitouch sequential thermostatic shower mixer 3/4"
Bottom outlet
1/2"
Offset STOP/CHECK connectors H9630 96 1/2"
In-line STOP/CHECK connectors - tested without water
(NHS compliant) H963015 141
Offset standard connectors H9630S 150
Without connectors for renovation 9630 150 ±20
1/2"
Top outlet
Offset STOP/CHECK connectors H9640
In-line STOP/CHECK connectors - tested without water H964015
(NHS compliant)
Offset standard connectors H9640S
Options: hydrotherapy accessories (see pages 137 - 139), BIOFIL shower head 184 184
filters (see page 138), auto-draining device (see page 140), floor traps (see page 143)
H9630 H964015
110 Thermostatic shower mixers
