SECURITHERM sequential thermostatic mixers /

SECURITHERM recessed shower mixer
Sequential thermostatic mixer in a waterproof housing

• Mixer with scale-resistant sequential thermostatic cartridge:
- Opens and closes with cold water (see page 112).
- No risk of cross flow between hot and cold water.
No non-return valves on the inlets.
- Anti-scalding failsafe: automatic shut-off if cold water supply fails.
- Prevents cold showers: automatic shut-off if hot water supply fails.
- Temperature control: cold water up to 39°C. Maximum temperature limiter set at 39°C. SHOWERS
- For ref.s H9631L and H9633L: tested without water to comply with
NHS requirements (UK). No pre-set temperature.
- Thermal shocks are possible.
- Flow rate regulated at 9 lpm (mixer only), 6 lpm at 3 bar with shower head.
- M¾" inlets with integrated filters.
• Order a wall-mounted shower head or outlet to complete (see pages 133 and 141).
• Bright polished stainless steel wall plate 166 166mm.
• Recessed waterproof housing (see page 113):
225
- Collar with waterproof seal. 166x166
- Hydraulic connection from the outside and maintenance from the front. 1/2" 1/2" 1/2" 83-110
- Adjusts to all types of installation (rails, solid walls, panels).
- Compatible with wall finishes 10 - 120mm
(while maintaining the minimum recessing depth of 83mm).
- Suitable for standard or "pipe-in-pipe" supply.
- Stopcocks and flow rate adjustment, filters and cartridge 150
are all integrated and accessible from the front.
- Supplied in 2 kits: secure system flush without sensitive elements.
• Suitable for people with reduced mobility. 30-year warranty.
H96BOX+H9631L
SECURITHERM sequential thermostatic shower mixer with no shower head
recessed in a waterproof housing
Hygiene lever L. 100mm
225
No elbow outlet H96BOX 166x166
Tested without water (NHS compliant) + H9631L 1/2" 1/2" 1/2" 83-110
With elbow outlet H96CBOX
Tested without water (NHS compliant) + H9633L
ERGO control
H96BOX
No elbow outlet
+ H9631 150
H96CBOX
With elbow outlet
+ H9633
Options: fixed shower heads (see page 133), floor traps (see page 143)
H96BOX+H9631
Thermostatic shower mixers 115
