Mechanical shower mixers /
Auto-draining shower kit Shower kit with riser rail
With single control mechanical mixer With single control mechanical mixer
Shower kit with auto-draining device includes: Shower kit with riser rail includes:
• Ø 40mm standard ceramic or pressure-balancing cartridge. • Ø 40mm standard ceramic or pressure-balancing cartridge.
- Pre-set maximum temperature limiter. - Pre-set maximum temperature limiter.
- Flow rate regulated at 9 lpm. - Flow rate regulated at 9 lpm.
- Sculptured control lever. - Sculptured control lever.
- M½" outlet with integrated non-return valve. - M½" outlet with integrated non-return valve.
• Shower head with flexible hose and chrome-plated, • Sliding shower head on a chrome-plated riser rail SHOWERS
wall-mounted tilting support. with flexible hose and soap dish.
• Auto-draining device FM½" automatically drains the flexible hose • Shower hose retaining collar.
and shower head (see page 140). • Suitable for people with reduced mobility.
• Suitable for people with reduced mobility. • 30-year warranty.
• 30-year warranty.
550
Ø 25
1,5m
0,85m
175
150 ±20 150 ±20 1/2"
1/2"
62
175 69
2539EPHYG 2539SKIT
Auto-draining mechanical shower kit Mechanical shower kit with riser rail
With pressure-balancing With pressure-balancing
Offset STOP/CHECK connectors 2539EPHYG Offset STOP/CHECK connectors 2539EPKIT
Offset standard connectors 2539EPSHYG Offset standard connectors 2539EPSKIT
With standard ceramic cartridge With standard ceramic cartridge
Offset STOP/CHECK connectors 2539HYG Offset STOP/CHECK connectors 2539KIT
Offset standard connectors 2539SHYG Offset standard connectors 2539SKIT
Options: soap dishes (see page 142), floor traps (see page 143), Options: auto-draining device (see page 140), floor traps (see page 143),
BIOFIL shower head filters (see page 138) BIOFIL shower head filters (see page 138)
Mechanical shower mixers 131
