/ Deck-mounted TEMPOMATIC 4 electronic controls


              TEMPOMATIC 4
              Electronic mixer and tap, mains supply or battery-operated







































              • 230/6V mains supply or integrated CR123 6V Lithium batteries.
              • Reduced-stagnation solenoid valve and electronic unit integrated into the body of the mixer/tap.
              • Scale-resistant flow straightener.
              • Duty flush (~60 seconds every 24 hours after last use).
              • Flow rate pre-set at 3 lpm at 3 bar, can be adjusted from 1.4 - 6 lpm.
              • Active, infrared presence detection, sensor at the end of the spout optimises detection.
              • Cap fixed in place by 2 concealed screws.                                   Standard lever  Long lever
              • PEX flexibles with filters and non-return valves.
              • Fixing reinforced by 2 stainless steel rods.
              • Anti-blocking security.
              • Side temperature control with adjustable maximum temperature limiter on mixers.
              • Suitable for people with reduced mobility.
              • 30-year warranty.














                                                                             Ø15mm for             70
                                                 F⅜" with   F⅜" without   F⅜" DZR
                                                 stopcock   stopcock  LEAD FREE  comp. fittings       70
                                                                             (UK/Ireland)
              TEMPOMATIC MIX 4 mixer                                                                 105    45 max
              Recessed mains supply               490000   490100   490100AS  49000015
                                                                                                  50x50x25
              Plug-in mains supply                490001   490101      -      49000115
              6V Lithium battery-operated         490006   490106   490106AS  49000615                        410
              TEMPOMATIC 4 tap
              Recessed mains supply               440000   440100   440100AS  44000015
              Plug-in mains supply                  -      440101      -         -
              6V Lithium battery-operated         440006   440106   440106AS  44000615                    3/8"
              We recommend installing a TMV for taps (see page 103)
              Option: for long lever, please add "LH" after the reference
              For compression fittings with copper tails, please add "CO" after the reference.
                                                                                                      490000
