TEMPOMIX 3 time flow shower controls /

                       •  Exceptional water savings: 80%
                       •  Vandal-resistant: chrome-plated solid brass, streamlined design
                       •  Comfort: temperature selection directly via the single control mixer, soft-touch operation



               TEMPOMIX 3                                           TEMPOMIX 3
               Exposed time flow shower kit                          Exposed time flow shower mixer









                                                                                                                             SHOWERS



























               • TEMPOMIX 3 single control mixer ¾".                • TEMPOMIX 3 single control mixer ¾".
               • For wall-mounted, exposed installation.            • For wall-mounted, exposed installation.
               • Temperature control and operation via the push-button.  75  • Temperature control and operation via the push-button.
               • Maximum temperature limiter                        • Maximum temperature limiter (can be adjusted by the installer).
                (can be adjusted by the installer).                 • Soft-touch operation.
               • Soft-touch operation.                              • Time flow ~30 seconds.
               • Time flow ~30 seconds.                              • Flow rate 6 lpm at 3 bar, can be adjusted from 6 - 12 lpm.
               • Flow rate 6 lpm at 3 bar, can be adjusted,         • Chrome-plated brass.
                comfortable rain-effect spray.                      • Integrated filters and non-return valves.
               • Chrome-plated, tamperproof TONIC JET shower head.  • Chrome-plated metal push-button.
               • Chrome-plated brass.                               • Offset connectors M½", for centres 130 - 170mm.
               • Integrated filters and non-return valves.          • Suitable for people with reduced mobility.
               • Chrome-plated metal push-button.                   • 30-year warranty.
               • Reinforced shower column Ø 16mm and collar
                (mounting bracket and screws included).
               • Offset connectors M½", for centres 130 - 170mm.  1000                                            130
               • Suitable for people with reduced mobility.                       1/2"   50  3/4"           1/2"
               • 30-year warranty.
                                                                      150  130 min - 170 max  130  150  130 min - 170 max  50  3/4"

                                                                                                               23   1/2"
                                                                      Ø 65                        Ø 65
                                                794450                            794400                794470



                                                        1/2"
                                                             130
                                                                    TEMPOMIX 3 exposed mixer
                                                                    Top inlet M¾"                              794400
               TEMPOMIX 3 exposed shower kit              794450    Bottom inlet M¾" with union M½"            794470
               We recommend installing a floor trap (see page 131)   We recommend installing a floor trap (see page 131)
               Option: STOP/CHECK connectors (see page 136)         Options: STOP/CHECK connectors (see page 136) and shower heads (see page 134)
