TEMPOMIX time flow shower controls /

• Exceptional water savings: 80%
• Comfort: temperature selection directly via the single control mixer, soft-touch operation
• Vandal-resistant: chrome-plated ligature-resistant collar, concealed fixings

TEMPOMIX TEMPOMIX TEMPOMIX
Time flow shower kit Cross wall time flow shower kit Time flow shower mixer

SHOWERS

• Chrome-plated metal or stainless steel wall plate. • TEMPOMIX ¾" single control mixer. • TEMPOMIX ¾" single control mixer.
• Standard recessed housing. • For walls ≤ 220mm. • For wall-mounted, exposed installation.
• Recessing depth can be adjusted. • Temperature control and operation via • Temperature control and operation via
• TEMPOMIX single control mixer ¾". the push-button. the push-button.
• Ligature-resistant collar. • Maximum temperature limiter (can be adjusted • Maximum temperature limiter (can be adjusted
• Temperature control and operation via by the installer). by the installer).
the push-button. • Ligature-resistant collar. • Soft-touch operation.
• Maximum temperature limiter (can be adjusted • Soft-touch operation. • Time flow ~30 seconds.
by the installer). • Time flow ~30 seconds. • Flow rate 12 lpm at 3 bar, can be adjusted.
• Time flow ~30 seconds, soft-touch operation. • Flow rate 6 lpm at 3 bar, comfortable • Chrome-plated solid brass body.
• Flow rate 6 lpm or 12 lpm at 3 bar, rain-effect spray. • Integrated filters and non-return valves.
comfortable rain-effect spray. • Chrome-plated, tamperproof ROUND shower • Chrome-plated metal push-button.
• Chrome-plated, tamperproof ROUND shower head with automatic flow rate regulation. • Available with or without elbow unions.
head with automatic flow rate regulation. • Chrome-plated brass valve body and shower • 30-year warranty.
• M½" connections for copper tails. head.
• Integrated filters and non-return valves. • Integrated filters and non-return valves.
• Chrome-plated metal push-button. • Chrome-plated metal push-button.
• 30-year warranty. • Threaded rods can be cut to size.
• 30-year warranty.
1/2" 230 max 35

Ø 21
28-48
28-43
1/2" 1/2"
30 120 min 220 max Ø 70 55 30 30
1/2"
105x130x60 Ø 195 105x130x60 160 x 160 45 Ø 21 3/4" 3/4" 3/4"
1/2"
3/4" 3/4"
30-40 30-40
790927 790427 796209 790874 790000

TEMPOMIX shower recessed in standard housing
Kit with shower head (flow rate - 6 lpm)
With wall plate Ø 195mm and ROUND 790909
shower head TEMPOMIX exposed mixer
With st. steel wall plate 160 160, 790709 With elbow unions 150mm centres 790874
ROUND shower head With in-line unions 90mm centres 790000
Mixer without shower head For panels 1 - 10mm 790970
(flow rate - 12 lpm adjustable)
Reinforced wall plate Ø 80mm.
With wall plate Ø 195mm 790927
TEMPOMIX cross wall shower kit 796209 Recommended for installing on panels 824800
With stainless steel wall plate 790427 We recommend installing a floor trap (see page 131) or dry walls
160 160mm
Other cross wall lengths available on request We recommend installing a floor trap (see page 131)
We recommend installing a floor trap (see page 131) (minimum order of 200 units) Option: shower heads (see page 134)
Showers 123
