Mirror cabinet with 3 or 4 functions /

• Design: 304 stainless steel cabinet with matte black finish
• Hygiene: no manual contact
• Comfort: 3 or 4 functions in one place

Mirror cabinet with 3 or 4 functions

BASINS
• Mirror cabinet with 3 or 4 functions: mirror, electronic
NEW soap dispenser, electronic tap (included in 4 function
models) and hand dryer or paper towel dispenser.
• Designer cabinet in 304 stainless steel with matte black
melamine finish.
• Touch-free for improved hygiene:
soap dispenser, tap and hand dryer are automatically
activated when hands are detected by infrared sensor.
• Quick and easy to install:
- A single electrical connection for all the elements:
230V / 50 60Hz mains supply via transformer.
- Connects to the water supply from the top or from inside
the cabinet.
- M⅜" water connection.
- Concealed fixings: supplied with stainless steel screws
for concrete walls or reinforced wood.
- Adjustable hinges.
• Glass mirror and black glass strip with illuminated
pictograms.
• Electronic soap dispenser:
- No-waste pump dispenser.
- Large capacity tank: 5 litres.
- Suitable for plant-based liquid soap with a maximum
viscosity of 3,000 mPa.s or specific foam soap.
• Electronic basin tap (included in 4 function models):
- Reduced stagnation solenoid valve.
600 223 - Flow rate pre-set at 3 lpm at 3 bar, adjusts from 1.4
to 6 lpm.
- Scale-resistant flow straightener.
- Duty flush (~60 seconds every 24 hours after last use).
- Stopcock.
• Models with air pulse hand dryer :
- High speed dryer.
1000 - Pulsed air at 360 km/h. Airflow: 36 l/second.
- Low energy consumption: 704W.
- Noise level: 74 dBA.
- Class I, IP23. CE marked.
- 3-year warranty.
• Models with paper towel dispenser:
- Dispenses one sheet at a time.
190 190 172
- Dimensions: 120 × 275 × 360mm.
510203 - Capacity: 500 sheets.
Awards: • LED strip downlights for the basin.
Mirror cabinet with 4 functions • Vandal-resistant model with lock and standard
DELABIE key.
With hand dryer
• Anti-blocking: stops water automatically if continuous
Width 600 mm 510203
use is attempted.
Width 800 mm 510204 • Internal storage shelf.
With paper towel dispenser • Several cabinets can be installed side-by-side to create
Width 600 mm 510205 a mirror wall: linking screws are provided.
Width 800 mm 510206 • CE marked.
• 30-year warranty (3-year for the hand dryers).
Mirror cabinet with 3 functions - for deck or wall-mounted water controls
With hand dryer
Width 600 mm 510207
Width 800 mm 510208
With paper towel dispenser
Width 600 mm 510209
Width 800 mm 510210
TMV for models with taps
PREMIX NANO tmv F1/2" - Ø 15mm 732115MEC
for compression fittings + connector + 808012

Basins 27
