Spouts /

Fixed, cast spout Swivelling swan neck spout Tubular spout
Deck-mounted Deck-mounted Deck-mounted

BASINS

• Spout L. 140mm, H. 120mm, M½". • Swan neck spout M½". • Tubular spout on base M½".
• Reinforced fixing by 3 stainless steel screws. • Fixing by back-nut. • Chrome-plated brass.
• Chrome-plated solid brass. • Chrome-plated brass. • Spout with smooth interior
• Scale-resistant flow straightener regulated • Scale-resistant flow straightener regulated (reduces bacterial development).
at 3 lpm. at 3 lpm. • Scale-resistant flow straightener.
• 30-year warranty. • 30-year warranty. • 30-year warranty.

150
170
120 120
150
1/2"
1/2" 1/2" 15 max
140 30 max 30 max
981142 967152 204001
Swivelling tubular spout Ø 22mm
L. 150mm H. 140mm, 3 lpm 1306T1
Swivelling swan neck spout L. 200mm H. 260mm, 3 lpm 1306T2
L. 150mm H. 120mm 967152 L. 300mm H. 260mm 1306T3
Fixed, cast spout 981142 L. 200mm H. 200mm 967202 Fixed tubular spout Ø 16mm 204001

Fixed spout Fixed spout Fixed L-shaped spout
Wall-mounted / Cross wall For slim panels Wall-mounted

• Spout Ø 32mm, M½". • Spout L. 75mm, M½". • Tubular spout Ø 18mm, M½".
• Chrome-plated brass. • For slim panels. • L. 120mm.
• Scale-resistant flow straightener regulated • Threaded rod can be cut to size. • Chrome-plated brass.
at 3 lpm. • Streamlined, ligature-resistant design. • Flow straightener.
• 30-year warranty. • Chrome-plated brass. • 30-year warranty.
• Star-shaped scale-resistant flow straightener.
Ø 32 Ø 60 Ø 21 1/2" • 30-year warranty.

120 165 max
Ø 48 Ø 21 1/2" 10 max 1/2"
947151 60
75 30 max 120
Cross wall spout with wall plate
L. 120mm 947151 942040 941922
L. 170mm 947157
Wall-mounted spout no wall plate (recessed inlet)
L. 110mm 947120
Wall-mounted L-shaped universal spout
L. 160mm 947170 Cross wall fixed spout Star-shaped flow straightener 941120
Wall-mounted spout with wall plate (recessed inlet) For panels ≤ 30mm 942040
Flow straightener regulated
L. 120mm 947135 Back-nut with 3 screws 826315 at 3 lpm for panels ≤ 10mm 941922

Basins 73
