/ Additional fittings

Offset connector In-line connector ECO flow straightener
Standard With STOP/CHECK Pre-set at 3 lpm

• Offset standard connector 11mm. • Chrome-plated brass connector. • Flow straightener pre-set at 3 lpm
• M½" - M¾". • M½" - M¾". (DELABIE patented).
• Escutcheon Ø 64mm. • Escutcheon Ø 65mm. • Flow rate can be adjusted from 1.4 - 6 lpm
• L. 50mm. • STOP function: integrated stopcock. at 3 bar (depending on the mixer/tap model)
• Chrome-plated brass. • CHECK function: checks if non-return valves from the outside with a 2.5mm Allen key.
• Supplied in packs of 2. are watertight where fitted to mixers • Flow straightener with no grid:
• 30-year warranty. (DELABIE patented). reduces bacterial development
• Supplied in packs of 2. (no water retention or scale deposits).
• 30-year warranty. • Supplied in packs of 2.

Ø 64 The water savings generated by the ECO flow
1/2"
3/4" Ø 65 Ø 65 straightener surpass the requirements of class
1/2" Ø 44 'Z' of the European standard EN 246.
11 3/4" 1/2" 3/4"
24/100
12
50 15 35
35 max 15 max HEX 2,5
22,5 min 15 max
90
62,2
856794.2P 922024.2P C282025
855755.2P 855755UK.2P
Scale-resistant ECO flow straightener
Wall connector with STOP/CHECK M24 100 922024.2P
Offset 12mm 855755.2P F22 100 922022.2P
Offset standard connector 856794.2P In-line for cross wall installation 855755UK.2P 2.5mm Allen key C282025
ECO aerator Comfort aerator BIOSAFE outlet
1.4 lpm M16.5 100 M16.5 100

• Rain effect aerator. • Aerator with comfortable spray. • BIOSAFE free flow hygienic outlet.
• 1.4 lpm. • M16.5 100. • M16.5 100.
• Ref. 925716.2P to screw in. • Supplied in packs of 2. • With no grid or partitions in contact
• Ref. 925724.2P to insert in an aerator carrier. with the water.
• Complies with environmental label • Water cannot stagnate in the internal part
requirements. reducing bacterial development.
®
• Supplied in packs of 2. • Made from Hostaform reducing the build-up
of scale.
• For TEMPOMIX 3 recessed and TEMPOMATIC 4
wall-mounted.
34 • Supplied in packs of 2.

16,5×100 Ø 21 16,5×100 16,5×100
11,5 16 13,6 Ø 16,4 17

925716.2P 925724.2P 925616.2P 222429 923016.2P

ECO aerator Aerator 16.5Mx100 BIOSAFE outlet M16.5 100
M16,5 100 925716.2P Aerator 925616.2P BIOSAFE outlet 923016.2P
M24 100 925724.2P Service key 222429 Service key 222429
