Page 77 - water-controls-for-public-commercial-places

Additional fittings /

PREMIX NANO PREMIX COMPACT Pre-mixer Compact
Thermostatic mixing valve Thermostatic mixing valve

BASINS

• Thermostatic mixing valve for MW distribution. • Thermostatic mixing valve for MW distribution. • For installation beneath the basin.
• Temperature can be adjusted from 34 - 60°C. • Temperature can be adjusted from 30 - 60°C. • Nickel-plated body MF½".
• To be placed upstream of the tap. • To be placed upstream of the taps. • Non-return valves and filters can be checked.
• Anti-scalding failsafe. • Anti-scalding safety. • 30-year warranty.
• Filters and non-return valves. • Filters and non-return valves.
• Thermal shocks are possible. • Thermal shocks are possible.
• Supplies 1 - 2 taps. 75 • For 2 to 11 basin taps.
1/2"
• 30-year warranty. • 30-year warranty. 120
3/8"
1/2"
70 65
1/2" 1/2" 1/2" 1/2"
3/8" 34 3/8" 40 35
732012 733015 200000
PREMIX NANO
Nickel, FFM ⅜" 732012 PREMIX COMPACT
Polished, FFM ⅜" 732016 M½" 733015
Nickel, M½" Ø 15mm 732125 M¾" 733020
Nickel, F½" Ø 15mm 732115MEC M½" Ø 15mm 733125
Polished, M½" Ø 15mm 732126 M¾" Ø 15mm 733126
For NHS compliant versions, see page 155 For NHS compliant versions, see page 155 Pre-mixer Compact 200000

Hygienic waste ON/OFF waste HYGIÉNA waste
Without water level With stainless steel valve With concave grid

NEW

• Hygienic washbasin waste M1¼". • Washbasin waste M1¼" • Hygienic washbasin waste, M1¼".
• No water level: dome with a cup with a with stainless steel valve with free flow. • Concave grid (no water retention).
membrane which can be removed from above. • Recommended for all washbasins equipped • Free flow, with no central screw.
• Evacuation flow rate complies with European with electronic or time flow mixers/taps • Brass grid, ABS body.
standard EN 274: 36 lpm. and washbasins with an overflow. • Pre-scored waste: snap off sections can be
• Waste can be cut to size. • Open/close by pressing the top of the waste. removed for models with overflow (except
• Requires minimal space (54mm), • 30-year warranty. models for stainless steel basins).
no water retention. Ø 65 • 30-year warranty.
• 30-year warranty.
Ø 61 Ø 63
1 - 45 Ø 41,5 Ø 63
Ø 42 30 1 - 45 Ø 39
58 1-2 Ø 64 50
1"1/4 50 50 1"1/4
Ø 32 1"1/4
621 581000 611 6110

HYGIÉNA waste
Hygienic waste Chrome - For ceramic basins 611
White 621W Chrome - For stainless steel basins 6110
Chrome 621 ON/OFF waste 581000 Matte black - For stainless steel basins 6110BK

Basins 75
