Accessories Wastes and traps /

Hygienic waste without water level ON/OFF waste HYGIÉNA waste
Waste with membrane With stainless steel valve With chrome-plated brass concave grid

NEW

• Hygienic water-free waste M1¼". • Washbasin waste M1¼" with stainless steel • Hygienic washbasin waste, M1¼".
• Waste with a membrane to prevent bad smells. valve with free flow. • Concave grid (no water retention).
• No water level: dome with a cup with a • Recommended for all washbasins equipped • Free flow, with no central screw (avoids scale
membrane which can be removed from above. with electronic or time flow mixers & taps deposits and reduces bacterial development).
• Membrane can be cleaned and replaced. and washbasins with an overflow. • Polished chrome-plated brass grid,
• Evacuation flow rate complies with European • Open/close by pressing the top of the waste. chrome-plated ABS body.
standard EN 274 1: 36 lpm. • 30-year warranty. • Long model: can be tightened, min. 1mm,
• Waste can be cut to size. max. 45mm; pre-scored waste (snap off sections
• Not suitable for washbasins with an overflow. easy to remove for models with overflow).
• 30-year warranty. Short model: can be tightened, min. 1mm,
max. 2mm; for stainless steel washbasins.
Ø 65
• Complies with EN 274 1.
• 30-year warranty. Ø 63
1 - 45 Ø 41,5 Ø 61 Ø 63
1 - 45 Ø 39
Ø 42 30
58
1-2 Ø 64 50
50 50
1"1/4 1"1/4
Ø 32 1"1/4
621 581000 6110 611
Hygienic waste without water level HYGIÉNA waste BASIN & SINK ACCESSORIES
White 621W Long model 611
Chrome-plated 621 ON/OFF waste 581000 Short model 6110

Waste Waste with valve Trap with horizontal outlet
With stainless steel grid

• Stainless steel grid Ø 63mm • Outflow M1¼". • Inlet F1¼".
for covering holes up to Ø 54mm maximum. • Chrome-plated stainless steel. • Horizontal outlet Ø 32mm with nut.
• Outlet M1¼". • 30-year warranty. • Water level 50mm.
• Central screw. • Chrome-plated brass.
• 30-year warranty. • 30-year warranty.

1"1/4
51
Ø 63 180 max 30-95
Ø 63 Ø 32
30-40
50 max 85-95 90
30 1"1/4 1"1/4

580000 620 517000

Waste with stainless steel grid 580000 Stainless steel waste with valve 620 Trap with horizontal outlet 517000

Basin & sink accessories 99
