/ Spare parts Spout outlets, spouts and reinforced fixings

BIOSAFE OUTLETS, FLOW STRAIGHTENERS

BIOSAFE outlets free flow with no grids or partitions in contact with water (with brass collar)
F22 100 (1 piece) for taps/mixers 25061T1, 2506T1 & H9726 (5 lpm max.) 923022 -
F22 100 (50 pieces) for taps/mixers 25061T1, 2506T1 & H9726 (5 lpm max.) 923022.50P -
M24 100 (1 piece) for range 2520 (EP) (5 lpm max.) 923024 A
A B
M24 100 (50 pieces) for range 2520 (EP) (5 lpm max.) 923024.50P A
M24 100 (1 piece) for range 2620 (EP) (5 lpm max.) 926024 -
M24 100 (1 piece) for range 2640/2641 (5 lpm max.), 2564 & 2565, 2720 & 2820 922640 B
M16.5 100 (1 piece) for range 2920, 2664 & 2665 (5 lpm max.) (without brass collar) 922660 -
Hygienic flow straightener star-shaped without grid, reduces bacterial development (with brass collar)
F22 100 (2 pieces) 921022.2P -
C D F22 100 (50 pieces) 921022.50P -
M24 100 (2 pieces) 921024.2P C
M24 100 (50 pieces) 921024.50P C
Flow straighteners at 3 lpm flow rate can be adjusted using 2.5mm Allen key (with brass collar)
F22 100 with adjustable flow rate (2 pieces) 922022.2P D
M24 100 with adjustable flow rate (2 pieces) 922024.2P -
E Key for adjustment (2.5mm Allen key) C282025 E
Removal tool for flow straighteners 222429 -
Non-return valves
For ⅜" connection 900010 -

SPOUTS
300
Spouts L. 300mm
300
Over spout Ø 22mm, H. 230mm
230 with nut ¾", flow straightener inserted 963300245F F
130 Over spout Ø 22mm, H. 130mm
3/4" 3/4" with nut ¾", flow straightener inserted 963300145F G
F G
Under spout Ø 22mm, H. 80mm
200
with nut ¾" and flow straightener, not threaded 943300110 H
Spouts L. 200mm
3/4"
Over spout Ø 22mm, H. 230mm
80
230
300 with nut ¾", flow straightener set at 3 lpm (can be adjusted by 2.5mm Allen key) 963200245F I
Over spout Ø 22mm, H. 135mm
3/4"
H I with nut ¾", flow straightener inserted 963200145F J
Under spout Ø 22mm, H. 105mm
with nut ¾" and flow straightener, not threaded, for mixer 2519 943200100M K
200
3/4"
Swivelling under spout H. 45mm
105
with nut ¾", flow straightener inserted for 2436 & 2445 mixers 943200 -
200
135 Fixed under spout H. 45mm
3/4"
J K with nut ¾", flow straightener inserted for 2437 & 2455 mixers 947200 L
Spouts L. 150mm
150 Over spout Ø 22mm, H. 105mm
with nut ¾", flow straightener set at 3 lpm (can be adjusted by 2.5mm Allen key) 963150125F M
3/4"
45 Over spout Ø 22mm, H. 100mm
105
200
3/4" with nut ¾" and BIOSAFE outlet 963150923F -
Swivelling under spout H. 45mm
L M
with nut ¾", flow straightener inserted for 2446 mixers 943150 -
Fixed under spout H. 45mm
with nut ¾", flow straightener inserted for 2456 mixers 943151 -
FIXINGS
Reinforced fixing kits for deck-mounted mixers/taps for sinks
Fixing plate 256P N
Fixing plate with threaded rods 256FIX O
N O

202 Spare parts
