Spare parts Electronic controls /

SOLENOID VALVES
For basin, shower & WC controls
12V MM⅜" for TEMPOMATIC 1 & 2, BINOPTIC and TEMPOMATIC basin 495612 A
12V MM1" for TEMPOMATIC WC valves except 463326 461035 -
6V for TEMPOMATIC 3 basin (old design) 479651 B
A B
6V for TEMPOMATIC 3 basin (after May 2023) 479650 B
6V for TEMPOMATIC 4 basin (with adjustable flow rate) 479650 B
6V MM⅜" for TEMPOMATIC 1 & 2, BINOPTIC 495606 -
Electronic unit and start-up module for TEMPOMATIC WC dual control 763MODEV -
12V F1"-F1¼" for WC with backflow prevention device and stopcock
for TEMPOMATIC multifunction unit and TEMPOMATIC WC 463SRH -
C D

ELECTRONIC CONTROL UNITS
For basin, shower & WC controls
230/12V standard with "duty flush" option, with transformer for basins 495444BC C
230/12V multifunction with transformer for basins, showers, etc. 495445BC C
6V battery-operated for basins 495446BC C E F
6V with integrated battery for TEMPOMATIC 3 basins 492446 D
6V with integrated batteries for TEMPOMATIC 4 basins 490454 E
6V for TEMPOMATIC 4 basins, mains supply 490452T E
230/12V multifunction with transformer for dual flush type 463... 463000 F

ELECTRICAL SUPPLY CABLES G H

For TEMPOMATIC 4 basin controls with mains supply
6V recessed supply 490240 G
Extension 490230EXT -

SENSORS I J

For basin, shower & WC controls
With cable 0.70m 495070 H
With cable 1.50m 495149 H
For basins: BINOPTIC and TEMPOMATIC 2, cable 0.70m CEL378V -
For basins: BINOPTIC and TEMPOMATIC 2, cable 1.50m CEL378150V -
NB: cable cannot be extended or cut.

BATTERIES
For basin, shower & WC controls
2 3V Lithium batteries CR123 17345 990123 I
1 6V Lithium battery 223 CR - P2 990223 J

MAINTENANCE

Spare parts 203 INDEX
