/ Spare parts Cartridges for mechanical and thermostatic mixers

BASINS SINKS AND SHOWERS
Maintenance Complete
Mixers with ceramic cartridges kit cartridge Type
Ø 40mm cartridges
Standard cartridges
A B With base, with flow rate limiter
2206, 2406, 2420, 2421, 2445, 2446, 2452, 2455, 2456, 2520, 2521, 20121, 20421
2720, 2721 (up to 12/2022), 2820, 2821 (up to 05/2023) 2539, 2739 (up to 10/2016) - N009AG75 A
2220, 2221 (up to 12/2019), 2565 (up to 10/2020)
With base, without flow rate limiter
2211, 2211L (from 12/2017) - N109AG75 -
2239, 2252S, 2439, 2538, 2539, 2739
C D Without base, with flow rate limiter
20164T1, 20164T4, 20464T1, 20464T4, 20870T1, 20870T3, 20871T1, 20871T3 753256 N201AG75 -
New and old design Without base, without flow rate limiter
2519, 2543, 2597
2720/2820 range 2211, 2211L, 2599 (up to 12/2017), 2510 (up to 09/23) - N148AA75 -
Without base, with flow rate limiter
2246, 2410, 2443, 2561C, 2562C, 2569, 2595 - N248AA75 -
2564 (up to 10/2020), 2522 753256 N248AA75 -
2870 (up to 10/2021)
Without base, with 9 lpm flow rate limiter
2210, 2510 753256 N249AA75 -
Ø 35mm cartridges
2720, 2820 2720, 2820
Old design New design Standard cartridge with base
2506T2, 2506T3, 2542, 2599
2870/2871 range 2564Tx, 2565Tx (from 10/2020), 2870/2871 (from 10/2021) - NS262 -
2620, 2621, 2620MINI, 2621MINI - NSB262 -
2220, 2220L, 2221, 2221L (from 01/2020)
2506T1, 25061T1 - N222 -
2720, 2721 (from 12/2022), 2820, 2821 (from 05/2023)
Standard sequential cartridge with base
2437, 2437S - N243I -
2436, 2436S - N243 -
2870, 2871 2870, 2871 2640, 2640S, 2641, 2641S - N264 -
Old design New design
2564/2565 range Mixers with pressure-balancing ceramic cartridges
Ø 40mm cartridges with base
2211EP, 2211LEP, 2239EP, 2439EP, 2445EP, 2445LEP, 2446EP, 2446LEP,
2455EP, 2455LEP, 2456EP, 2456LEP, 2520EP, 2521EP, 2539EP, 2739EP,
2739TEP - N252 B
2720EP, 2721EP (up to 12/2022), 2820EP/2821EP (up to 05/2023)
2565TxEP (up to 10/2020)
Ø 35mm cartridges with base
2542EP, 2599EP, 2620EP, 2621EP, 2620MINIEP, 2621MINIEP,
2564, 2565 2564, 2565 2564TxEP, 2565TxEP, 2870TxEP, 2871TxEP (from 10/2020), - N262 -
Old design New design
2720/2721EP (from 12/2022), 2820/2821EP (from 05/2023)
2220/2221 range
Mixers with thermostatic cartridges
Sequential thermostatic cartridges
H9610, H9610S, H9611, H9611P, H9611S, H9614P, H9615 - N961 -
H9600, H9605, H9612, H9613, H9620, H9625, H9642 - N960 -
H9631, H9631L, H9633, H9633L - N962 -
9630, H9630, H963015, H9630S, H9632, H9634, H9635, H9636, H963615, - N963 -
H9637, H9638, H963915, H9640, H964015, H9640S, H964115
2220, 2221 2220, 2221
Old design New design Thermostatic cartridges
H9739 & H9739S - N97L -
H9600/H9605 range H9741, H9741TP & H9752P - N97LR C
H9716 & H9726 - N9726 -
9768, 9769, H9768, H9768S, H9768TP, H9769 & H9769S - N9769 -
792400, 792410, 792... - 743792 -
½" ceramic head, ¼-turn
9741, H9716, H9726, H9739, H9752S - 9741TET D

H9600/H9605 H9600/H9605
Old design New design

204 Spare parts
