Wall-mounted BINOPTIC electronic controls /

BINOPTIC
Recessed or cross wall electronic mixer and tap with mains supply

WALL-MOUNTED MIXERS & TAPS

• Independent IP65 electronic control unit.
• 230/12V mains supply with transformer.
• Scale-resistant flow straightener.
• Spout with smooth interior and low water volume (reduces bacterial
development).
• Adjustable duty flush (pre-set flush ~60 seconds every 24 hours after last use).
• Flow rate pre-set at 3 lpm at 3 bar, can be adjusted from 1.4 - 6 lpm. Standard lever
• Active, infrared presence detection, sensor at the end of the spout
optimises detection.
• Filters and solenoid valves.
• Chrome-plated brass body.
• Cable for sensor, flexibles and mounting all pass through the same hole
for cross wall model.
• Chrome-plated spout for cross wall or recessed installation.
• Anti-blocking security.
• Side temperature control with adjustable maximum temperature limiter
on mixer.
• Recommended installation height: 300mm above the basin surface.
• Suitable for people with reduced mobility.
• 30-year warranty.

110 max Ø 60
1/2"
230 200 17
110 x 75 x 40
110x75x40

Ø15mm for
M⅜" comp. fittings
(UK/Ireland) 3/8"
Cross wall BINOPTIC MIX mixer 379MCH 379MCH15
BINOPTIC wall-mounted tap
Recessed, spout L. 200mm 379ENC 379ENC15 Ø 15
Recessed, spout L. 252mm 379ENCL -
For walls ≤ 190mm, spout L. 205mm 379DER 379DER15
For walls ≤ 190mm, spout L. 135mm 379D13 379D1315
We recommend installing a TMV for taps (see page 103)
379MCH 379ENC15
Wall-mounted mixers & taps 87
