Wall-mounted sequential thermostatic mixers /

SECURITHERM mixer with BIOCLIP spout
Wall-mounted sequential thermostatic mixer, removable spout
Related products

BIOCLIP spouts
• Removable spout
for cleaning/disinfection.
• Hygienic flow straightener,
suitable for fitting a point-
of-use filter (see BIOFIL tap
filters page 23).

Ø 28 Ø 28

77
70
20004 20003

2 curved removable brass spouts L. 70mm 20004
2 straight removable stainless steel spouts Ø 28mm
L.129mm 20002 WALL-MOUNTED MIXERS & TAPS
L.77mm 20003

BIOCLIP
disposable spouts
• Removable, disposable
spout made from recyclable
Hostaform with star-shaped
®
• Sequential: opens and closes with cold water (see page 38).
• No risk of cross flow between hot and cold water. flow straightener.
No non-return valves on the inlets.
• Anti-scalding failsafe: immediate shut-off if cold or hot water supply fails.
• Securitouch thermal insulation prevents burns.
• Supplied with either 2 removable BIOCLIP brass spouts for continuous use during
®
cleaning/disinfection or with 1 disposable Hostaform spout. Ø 22
Can be replaced with a BIOFIL filter or stainless steel spout.
• Scale-resistant sequential thermostatic cartridge. 125
• Temperature control: cold water up to 40°C.
• Temperature limiter set at 40°C. 1/2"
• For ref.s H9611P, H9614P and H9615: tested 141
without water to comply with NHS requirements (UK). Ø 22 20015
No pre-set temperature. 65 185
• Thermal or chemical shocks are possible. 250 15 removable disposable spouts
• Body and spout with smooth interiors 1/2" L. 125mm, Ø 22mm 20015
(reduces bacterial development).
• Flow rate regulated at 7 lpm.
• No manual contact thanks to Hygiene 20
control lever L. 146mm. 150 ± 1/2" 184 BIOCLIP BIOFIL spouts
• Supplied with 2 wall connectors M½" M¾" • Anti-Legionella and all-
or pillar-mounted. germ removable spout filter.
• Suitable for people with reduced mobility. • Single use, sterilising grade
• 30-year warranty. H9610 0.1 m nominal-rated.
• Maximum lifespan 2 months
150mm 200mm
centres centres after installation.
• Compatible with
Wall-mounted sequential thermostatic mixer with BIOCLIP spout
and resistant to chemical
With disposable spout and thermal shocks in
Offset STOP/CHECK connectors H9610 - the water system (for more
Offset standard connectors H9610S - Ø 22 information see page 25).
With brass spout
Offset STOP/CHECK connectors H9611 - 138
Offset standard connectors H9611S -
In-line STOP/CHECK connectors H9611P* H9614P* 20040/30040
Pillar-mounted sequential thermostatic mixer H9615* -
with BIOCLIP spout 1 BIOFIL spout filter L. 138mm, Ø 22mm
* To comply with NHS regulation (UK), those references are water-free tested. Sterile 20040
Option: wastes (see page 99) Non-sterile 30040

Wall-mounted mixers & taps 89
