TEMPOMATIC Connect electronic direct flush systems /

                       •  Efficiency and water savings: direct flush system reduces the risk of leaks, powerful flush is available instantly
                       •  Hygiene: touch-free electronic flush, no cistern: no water stagnation (reduces bacterial development)
                       •  Specifically designed for public and commercial places: space saving, easy to clean, withstands intensive use
                       •  Easy to install: modular and adjustable waterproof housing for quick installation, or pre-mounted to frame system

               TEMPOFIX 3 with TEMPOMATIC Connect
               Frame system with electronic WC flush valve

                NEW                                                 • Black powder-coated steel frame.
                                                                    • Frame height can be adjusted from 0 - 200mm (with 1m mark).
                                                                    • Waterproof housing.
                                                                    • Ø 32mm flush tube with Ø 55mm connection washer.
                                                                    • ABS soil pipe with Ø 100mm outlet with waterproof seal,
                                                                     with 2 setting positions.
                                                                    • Delivered pre-mounted.
                                                                    • Compatible with solid wall finishes from 10 - 120mm.
                                                                    Available in 2 versions:
                                                                    Self-supporting frame system with large feet to fix to load bearing floors.
                                                                    Wall-mounted frame system to fix to load bearing walls.

                                                                    Fitted with TEMPOMATIC Connect F¾" electronic flush valve:
                                                                    • Flush system without cistern: directly connected to pipework.
                                                                    • Battery-operated with by CR123 6V Lithium batteries or mains supply
                                                                     230/6V (cable and transformer are supplied).
                                                                    • Satin finish or matte black stainless steel control plate 186   186mm.
                                                                    • Control plate is fixed manually via concealed screws.
                                                                    • Presence detection delay: 10 seconds.
                                                                    • Two activation modes:
                                                                     - touch-free, by passing the hand in front of the sensor,
                                                                     - an automatic flush that is activated after each user leaves.
                                                                    • Bluetooth configuration via the DELABIE Connect app
                                                                            ®
                                                                     (see pages 208 and 209) or manually set detection distance
                                                                     via the concealed button.
                                                      NEW           • "Intelligent" automatic rinsing: flush volume adapts according to use
                                                                     - 3L "short" usage, 6L "long" usage - (can be adjusted).
                                                                    • Vacuum breaker inside the housing.
                                                                    • Integrated stopcock and flow rate adjuster.
                                                                    • Supply pipe diameter: Ø 20mm minimum internal pipe diameter
                                                                     is required at all points (connectors included).
                                                                    • Base flow rate: 1 L/sec at 1 bar dynamic pressure.
                                                                    • Compatible with sea water, rainwater and grey water.
                                                                    • Suitable for rimless WC pans and people with reduced mobility.
                                                                                                                            CISTERN-LESS   WCs
                                                                    • 30-year warranty.





               Product currently under development.
               TEMPOFIX 3 WC frame system with TEMPOMATIC Connect
               Satin finish stainless steel control plate
                                                            564065
               Self-supporting model - 6V battery-operated                          186x186
                                                        + 465006                      3/4"
                                                                                                      10-120
                                                            564005
               Self-supporting model - 230/6V mains supply
                                                        + 465000
                                                            564060
               Wall-mounted version - 6V battery-operated
                                                        + 465006
                                                            564000
               Wall-mounted version - 230/6V mains supply
                                                        + 465000
               Matte black stainless steel control plate
                                                            564065
               Self-supporting model - 6V battery-operated                      1000-1320
                                                        + 465056
                                                            564005
               Self-supporting model - 230/6V mains supply
                                                        + 465050
                                                            564060
               Wall-mounted version - 6V battery-operated                                       300-620
                                                        + 465056
                                                            564000
               Wall-mounted version - 230/6V mains supply                           180-230
                                                        + 465050                                   165
                                                                                     350          157-177
               For Ø 90mm (or 110mm) soil pipe outlet versions: add "BE" (or "DE")
               after the reference for kit 1
               Options: wall fixings, sleeve connector and kit for disabled WC (see page 233)
                                                                                        564005 + 465000
