TEMPOMATIC electronic direct flush systems /

                       •  Efficiency and water savings: direct flush system reduces the risk of leaks, powerful flush is available instantly
                       •  Hygiene: touch-free electronic flush, no cistern: no water stagnation (reduces bacterial development)
                       •  Comfort: voluntary or automatic activation suitable for accessible washrooms
                       •  Vandal-resistant: cross wall installation or fixed frame system, concealed fixings

               TEMPOMATIC                                           TEMPOFIX 3 with TEMPOMATIC
               Cross wall electronic WC flush valve                  Frame system with electronic WC flush valve

                NEW                                                                                           Ø60







                                                                                                     1000-1320







                                                                                                         180-230
                                                                                                          350

               • Flush system without cistern:  directly connected to pipework.                       1"       70-210
               • Mains supply with 1" solenoid valve.
               • 230/12V transformer.
               • Independent IP44 electronic unit.
               • Cross wall installation.
               • Effective detection thanks to dual sensors.
               • Two activation modes:
                - touch-free, by passing the hand in front of the sensor,
                - an automatic flush that is activated after each user leaves.
               • Bluetooth configuration via the DELABIE Connect app
                       ®
                (see pages 208 and 209) or manually set detection distance
                via the concealed button.
               • "Intelligent" automatic rinsing: flush volume adapts according to use
                - 3L "short" usage, 6L "long" usage (can be adjusted).                               300-620
               • FF1" stopcock.
               • Ø 32mm vacuum breaker.                                                                 165
               • Ø 32/55mm connection washer.                                                          157-177
               • Escutcheon flush to wall. Threaded rod can be cut to size.
               • Supply pipe diameter: Ø 20mm minimum internal pipe diameter                            547105
                is required at all points (connectors included).                                                            CISTERN-LESS
               • Base flow rate: 1 L/sec at 1 bar dynamic pressure.   • Self-supporting frame system for wall-hung WCs:
               • Compatible with rainwater.                          with large feet for fixing to load-bearing floors.         WCs
               • Suitable for rimless WC pans and people with reduced mobility.   • Ø 32mm flush tube with Ø 55mm connection washer.
               • 30-year warranty.                                  • Ø 100mm PVC soil pipe with waterproof seal, with 2 setting positions.
                                                                    • Compatible with solid wall finishes from 70 - 210mm.
                                                                    • Fitted with a TEMPOMATIC F1" electronic direct flush valve:
                                                                     mains supply with 1" solenoid valve. 230/12V transformer.
                        1"   62             1"  62
                                                                    • Shock-resistant infrared presence detection sensor.
                                                                    • Voluntary activation (when hand is detected ~4cm in front
                                62                  62
                                                                     of the sensor) or automatic flush (when the user leaves).
                265          0,5m             265  0,5m             • Time flow ~7 seconds, can be adjusted from 3 - 12 seconds.
                                                                    • Base flow rate 1 L/sec at 1 bar dynamic pressure.
                             0,1m
                                                 0,1m
                 115                      115                       • Suitable for rimless WC pans without flow rate regulation.
                                Ø 29      Ø 32           200 max    • Suitable for people with reduced mobility.
                Ø 55  Ø 32  Ø 32  Ø 32     Ø 32  Ø 55  4m  Ø 32  Ø 21  Ø 32  • 30-year warranty.
                   1,5m           Ø 60  1,5m                     Ø 60
                          4m  30 max
                     464100                      464200
               Product currently under development.
               TEMPOMATIC WC cross wall
               For panels ≤ 30mm                          464100
                                                                    TEMPOFIX 3 WC self-supporting frame system
               For walls ≤ 200mm                          464200    with TEMPOMATIC WC                         547105
               Alternative cross wall lengths available on request  Options: wall fixings, sleeve connector and kit for disabled WC (see page 233)

                                                                                                    Cistern-less WCs  215
