P. 216

/ TEMPOMATIC dual control remote electronic direct flush systems

                         •  Efficiency and water savings: direct flush reduces the risk of leaks, powerful flush is available instantly
                         •  Hygiene: automatic flush, no cistern: no water stagnation (reduces bacterial development)
                         •  Comfort: suitable for WCs for people with reduced mobility, touch-free automatic flush or by pushing side control
                         •  Easy to install: modular and adjustable waterproof housing

                 TEMPOMATIC dual control remote
                 Recessed electronic direct flush valve


































                 • Flush system without cistern: directly connected to pipework.
                 • Battery-operated with CR123 Lithium 6V batteries or 230/6V mains                 Automatic flush activation when
                  supply (cable and transformer supplied).                                          the user leaves
                 • Satin stainless steel electronic control plate 186   186mm.                           Or voluntary using
                 • Satin stainless steel time flow control plate                                          the side control
                  with chrome-plated button, 90   90mm.
                 • Recessed waterproof housing:
                  - Collar with waterproof seal.
                  - Hydraulic connection from the outside and maintenance from the front.
                  - Adjusts to all types of installation (rails, solid walls, panels).
                  - Compatible with wall finishes from 10 to 120mm (while maintaining
                     the minimum recessing depth of 93mm).
                  - Suitable for standard or "pipe-in-pipe" supply.
                  - Stopcock, flow rate adjustment and electronic unit are integrated
                     and accessible from the front.
                  - TEMPOMATIC F¾" flush valve is compatible with sea water,
                     rain water and grey water.
                  - Vacuum breaker inside the housing.
                 • Shock-resistant infrared presence detection sensor.
                 • Presence detection delay: 10 seconds.
                 • Touch-free automatic activation when the user leaves
                  or voluntary by pressing the side control.
                 • AB anti-blocking system: water will flow only when the push-button    225  93-190
                                                                                          3/4"
                  is released.
                 • "Intelligent" automatic rinsing: flush volume adapts according to use
                  - 3L "short" usage, 6L "long" usage - (can be adjusted to 2L/4L or 5L/9L).             90x90  50
                 • 3 programmes (rinsing volume can be set according to type of WC pan).  150
                 • Hygienic duty flush every 24 hours (can be adjusted to 12 hours or OFF)          186x186        11
                  after the last use.
                 • Outlet connection for PVC tube Ø 26/32mm.
                                                                                             464300
                 • Supply pipe diameter: Ø 20mm minimum internal pipe diameter
                  is required at all points (connectors included).
                 • Base flow rate: 1 L/sec. at 1 bar dynamic pressure.
                 • Suitable for rimless WC pans and for people with reduced mobility.  TEMPOMATIC WC dual control remote
                 • 30-year warranty.                                  6V battery-operated                        464306
                                                                      230/6V mains supply                        464300
                                                                      We recommend a flush tube (see page 232)
