TEMPOFLUX 3 time flow direct flush systems /

                       •  Efficiency and water savings: direct flush reduces the risk of leaks, powerful flush is available instantly, dual flush 3L/6L
                       •  Hygiene: no cistern: no water stagnation (reduces bacterial development)
                       •  Comfort: soft-touch operation, low acoustic level complies with European standard EN 12541 class II
                       •  Easy to install: modular and adjustable waterproof housing (for walls and panels)

               TEMPOFLUX 3
               Recessed time flow direct flush valve





































                                                                                     225          93-190
               • Flush system without cistern: directly connected to pipework.      170x170        3/4"
               • Chrome-plated metal control plate 170   170mm,
                satin stainless steel 210   162mm,
                or black tempered glass 205   190mm.
               • Control plate fixed manually via concealed screws.             150
               • Recessed waterproof housing:
                - Collar with waterproof seal.                                                                              CISTERN-LESS
                - Hydraulic connection from the outside and maintenance from the front.
                - Adjusts to all types of installation (rails, solid walls, panels).    763BOX + 763040                       WCs
                - Compatible with wall finishes 10 - 120mm                             225           93-190
                   (while maintaining the minimum recessing depth of 93mm).          210x162
                                                                                                 3/4"
                - Suitable for standard or "pipe-in-pipe" supply.
                - Stopcock and flow rate adjustment, activation unit
                   and cartridge are all integrated and accessible from the front.
                - TEMPOFLUX 3 F¾" flush valve is compatible with sea water,      150
                   rain water and grey water.
                - Vacuum breaker inside the housing.
                - Supplied in 2 kits: secure system flush without sensitive elements.
               • Soft-touch operation.                                                 763BOX + 763000
               • AB anti-blocking system: water only flows when push-button
                is released.
               • Dual flush 3L/6L, can be adjusted to 2L/4L or single flush 6L.
               • Outlet connection for PVC tube Ø 26/32mm.                              Awards:
               • Acoustic level complies with European standard EN 12541 class II.  TEMPOFLUX 3 WC recessed in waterproof housing
               • Supply pipe diameter: Ø 20mm minimum internal pipe diameter                                   763BOX
                is required at all points (connectors included).    Chrome-plated metal control plate, dual flush
                                                                                                              + 763040
               • Base flow rate: 1 L/sec. at 1 bar dynamic pressure.
               • Suitable for rimless WC pans and for people with reduced mobility.  Chrome-plated metal control plate, single flush  763BOX
                                                                                                              + 763041
               • 30-year warranty.
                                                                                                               763BOX
                                                                    Satin stainless steel control plate, dual flush
                                                                                                              + 763000
                                                                                                               763BOX
                                                                    Black glass control plate, dual flush
                                                                                                              + 763030
                                                                    We recommend a flush tube (see page 232)
                                                                                                    Cistern-less WCs  217
