Page 182 - water-controls-for-public-commercial-places
P. 182

/ TEMPOSTOP  time flow urinal valves

                         •  Exceptional water savings: 60%
                         •  Vandal-resistant: recessed installation




                 TEMPOSTOP                                            TEMPOSTOP
                 Recessed time flow urinal valve                       Recessed time flow urinal valve























                 • For standard or siphon action urinals.             • For standard or siphon action urinals.
                 • For recessed installation.                         • For recessed installation.
                 • Recessing depth can be adjusted.                   • Recessing depth can be adjusted.
                 • Stainless steel plate Ø 130mm.                     • Stainless steel plate 160 x 160mm.
                 • Compatible with rain water.                        • Compatible with rain water.
                 • Time flow ~7 seconds.                               • Time flow ~7 seconds.
                 • Flow rate pre-set at 0.25 L/sec. at 3 bar, can be adjusted.  • Flow rate pre-set at 0.25 L/sec. at 3 bar, can be adjusted.
                 • Chrome-plated brass body F½" or M½".               • Chrome-plated brass body F½".
                 • 30-year warranty.                                  • 30-year warranty.
                 This model does not have a waterproof recessing housing. The installer   This model does not have a waterproof recessing housing. The installer
                 must ensure that the recessing area is waterproof and any leaks or   must ensure that the recessing area is waterproof and any leaks or
                 condensation can drain away (see installation guide).  condensation can drain away (see installation guide).









                             25-40                                                           25-45
                                                  20-35
                             1/2"                                                             1/2"
                                                 M 1/2"
                          72                    62                                         73
                             1/2"                                                             1/2"
                                                 M 1/2"



                            779128                777930                                     779427














                 TEMPOSTOP recessed valve with wall plate
                 F1/2” inlet                                779128
                 M1/2” inlet                                777930    TEMPOSTOP recessed valve with wall plate   779427


                 180 Urinals
