TEMPOSTOP  time flow urinal valves /

                       •  Exceptional water savings: 60%






               TEMPOSTOP                                            TEMPOSTOP
               Cross wall time flow urinal valve                     Exposed time flow urinal valve M½"























               • For standard or siphon action urinals.             • For standard, siphon action, or stall urinals.
               • For walls ≤ 200mm.                                 • For wall-mounted, exposed installation.
               • Compatible with rain water.                        • Compatible with rain water.
               • Time flow ~3 seconds.                               • Time flow ~3 seconds.
               • Flow rate pre-set at 0.15 L/sec. at 3 bar, can be adjusted.  • Flow rate pre-set at 0.15 L/sec. at 3 bar, can be adjusted.
               • Chrome-plated metal body M½".                      • Chrome-plated brass body M½".
               • Push-button base with anti-rotating pin.           • Escutcheon.
               • Connecting nut.                                    • 30-year warranty.
               • Threaded rod can be cut to size.
                                                                                                                             URINALS
               • 30-year warranty.














                                                                                Ø 50                   Ø 50
                                 110 max  200 max                                      1/2"        1/2"
                              1/2"                4
                                                                            62
                              60                  Ø50                                              30
                                                                                         1/2"
                              1/2"           Ø21
                                                                                  35                    35     1/2"
                                     777110                                      777000                778000












                                                                    TEMPOSTOP exposed urinal valve M½"
                                                                    Straight for in-line inlets                777000
               TEMPOSTOP cross wall urinal valve          777110    Angled for recessed inlets                 778000
               Alternative cross wall lengths are available on request  Options: unions and neck tubes (see page 182)
