P. 184

/ Additional fittings Unions and neck tubes



                 Elbow union                        Neck tube                          Neck tube
                 With or without stopcock           For siphon action urinals          For standard or siphon action urinals













                 • Retractable nut.                 • F¾" Ø 35mm.                      • F½" Ø 35mm.
                 • Chrome-plated brass.             • IDEAL STANDARD Prival 3803.      • ALLIA GEBERIT Satolas 43650/43651
                 • L. 30mm.                         • NOVOBOCH Mistal or Vasco.          or Blagnac 3560.
                 • 30-year warranty.                • ROCA wall-mounted.               • DURAVIT Ben 848.7, Pago 839.6, Jim or Neiße.
                                                    • SELLES 8620 or Mistal.           • IDEAL STANDARD Pindard.
                                                    • VILLEROY & BOCH Targa 7502/7504   • LAUFEN Como.
                                                     or Esta 7508.                     • NOVOBOCH Oural 600.
                      1/2"  Ø 50  1/2"  Ø 50
                                                    • 30-year warranty.                • PORCHER Axif.
                                                                                       • SELLES Euroline.
                             30           27                                           • SPHINX Eurobase.
                         30   1/2"    30  1/2"                                         • VILLEROY & BOCH Java, Toboga, Troja,
                                                                                         Magnum, Targa, Esta.
                                                                    3/4"                                     1/2"
                         836015     838015                                             • 30-year warranty.

                                                                      20                                       20
                 Elbow STOP union with stopcock                165                                      165
                 MF½", H. 30mm            836015                Ø 50                                     Ø 50
                                                                        Ø 35                                     Ø 35
                 M½" - F¾", H. 30mm ± 2mm  836020
                 Elbow union without stopcock
                                                                  759000                                  752000
                 MF½", H. 27mm            838015
                 M½" - F¾", H. 29mm       838020    Neck tube F¾" Ø 35mm      759000    Neck tube F½" Ø 35mm     752000


                 Neck tube                          Neck tube                          Neck tube
                 For DELABIE urinals                For ALLIA / SELLES urinals         For I.S. / PORCHER urinals













                 • F½".                             • F½" with water nozzle.           • IDEAL STANDARD Exposed 3873.
                 • DELABIE FINO or DELTA.           • ALLIA GEBERIT Aubagne.           • PORCHER Exposed 2642/2651.
                 • 30-year warranty.                • SELLES 8418.                     • 30-year warranty.
                 For matching urinals see DELABIE "Stainless   • 30-year warranty.
                 Steel Sanitary Ware" catalogue (DOC 750UK).
                                                                                                        1/2"
                                                                     1/2"
                          1/2"
                                          1/2"
                           Ø 12
                                                                                                     140  13
                     327              240  14                     245                                   3/8"
                                           Ø 39
                      170°
                                                                                                      753000
                           Ø 39
                           3/8"           3/8"
                        757135         757162                     751000
                                                                                        Neck tube F½", for I.S. / PORCHER urinals
                                                                                        IDEAL STANDARD F½" - F⅜"
                 Neck tube F½", for DELABIE urinals                                     Exposed 3873
                                                                                                                 753000
                 FINO                     757135
                                                    Neck tube F½" for ALLIA / GEBERIT   PORCHER F½" - F⅜"
                 DELTA                    757162    Aubagne, SELLES 8418 urinals  751000  Exposed 2641/2651
                 182 Urinals
