TEMPOCHASSE time flow direct flush systems /

                        •  Efficiency and water savings: direct flush reduces the risk of leaks, powerful flush is available instantly
                        •  Hygiene: no cistern: no water stagnation (reduces bacterial development)
                        •  Vandal-resistant: chrome-plated solid brass, shock-resistant mechanism, for recessed or cross wall installation




               TEMPOCHASSE                        TEMPOCHASSE                         TEMPOCHASSE
               Recessed WC flush valve             Exposed WC flush kit                 Exposed WC flush valve























               • Flush system without cistern: directly   • Flush system without cistern: directly   • Flush system without cistern: directly
                connected to pipework.             connected to pipework.              connected to pipework.
               • Satin stainless steel control plate 320   220mm.  • For wall-mounted, exposed installation.  • For wall-mounted, exposed installation.
               • Time flow ~7 seconds.             • Time flow ~7 seconds.              • Time flow ~7 seconds.
               • Vacuum breaker.                  • Vacuum breaker.                   • Vacuum breaker.
               • In-line cast brass stopcock and flow rate/  • F1" chrome-plated brass stopcock    • Chrome-plated brass body and push-button.
                flush volume adjuster.              and flow rate/flush volume adjuster.  • Shock-resistant mechanism.
               • Brass body and chrome-plated push-button.  • Chrome-plated brass body and push-button.  • In-line inlet M1¼".
               • Shock-resistant mechanism.       • Shock-resistant mechanism.        • Base flow rate: 1 L/sec. at 1 bar dynamic
               • In-line inlet F1".               • Connection washer Ø 32/55mm with clamp.  pressure.
               • Connection washer Ø 32/55mm.     • Base flow rate: 1 L/sec. at 1 bar dynamic   • Compatible with rain water.
               • Base flow rate: 1 L/sec. at 1 bar dynamic   pressure.                 • 30-year warranty.
                pressure.                         • Compatible with rain water.
               • Compatible with rain water.      • Bright polished stainless steel elbow flush
                                                                                                        1"1/4
               • 30-year warranty.                 tube Ø 32mm with nut and collar.
                                                  • 30-year warranty.
               This model does not have a waterproof recessed                                       110
               housing. The installer must ensure that                                                  1"1/4
                                                                                                     33
               the recessing area is waterproof and any leaks
               or condensation can drain away (see installation                                                             CISTERN-LESS
               guide).                                                                              760000
                                                                   1"                                                         WCs
                                                                                                     1"
                            100 min
                            1"                                                                      92
                                                                    Ø 32                           1"1/4

                         290 x 165 x 100  320 x 220           865 max  205 max                      764000



                                                                                                   1"
                                                                                                         42
                                 65-85
                                                                        Ø 55                         33   1"1/4
                                   Ø 55
                                                                  760004                            765000
                                  Ø 32

                             760220                TEMPOCHASSE WC exposed kit
                                                   For conventional WC pans
                                                   With in-line stopcock    760004    TEMPOCHASSE WC exposed
                                                   With elbow stopcock      760005    With push-button         760000
                                                   For slop hoppers                   In-line stopcock         764000
               TEMPOCHASSE WC recessed   760220                                       Elbow stopcock           765000
                                                   With in-line stopcock    760460
               We recommend a flush tube (see page 232)  and straight flush tube        We recommend a flush tube (see page 232)
