/ Additional fittings


                 Flush tube for WC pans                               Flush tube for WC pans
                 For recessed flush system / cross wall                For recessed flush system / cross wall

















                 • For TEMPOMATIC, TEMPOFLUX 1, TEMPOFLUX 2, TEMPOFLUX 3    • For TEMPOMATIC, TEMPOFLUX 1, TEMPOFLUX 2, TEMPOFLUX 3
                  and TEMPOCHASSE.                                     and TEMPOCHASSE.
                 • PVC tube for recessed                              • PVC tube for recessed or cross wall installation.
                  or cross wall installation.       Ø 32              • Ø 26/32mm (bare, without connection washer).
                 • With connection washer and HDPE pipe.              • 30-year warranty.
                 • Walls ≥ 60mm fix with bracket and screws.
                 • Ø 26/32mm.                                                                              Ø 32
                 • 30-year warranty.
                                               703-783

                                                                                                       780
                                      769500            670                                   769400
                                                        Ø 32                                                    434
                                                                  Ø 55



                 Flush tube with connection washer for recessing for WC pans  769500  Bare flush tube for recessing for WC pans  769400


                 Flush tube for WC pans                               Flush tube for squat WCs
                 For TEMPOFLUX 1 and 3 exposed and compact            For TEMPOCHASSE exposed

















                 • Bright polished stainless steel elbow flush tube Ø 28mm    • Elbow flush tube Ø 32mm with nut 1¼".
                  with collar and no nut.                             • Collar and connection washer Ø 32/55mm with clamp.
                 • With connection washer Ø 28/55mm with clamp.       • 30-year warranty.
                 • 30-year warranty.                                                                    1"1/4

                                                   Ø 28                                                  Ø 32



                                             505                                                  670  38
                                              28

                                      766002          215                                 766001           205
                                                        Ø 55                                                 Ø 55



                 Flush tube for WC pans                     766002    Flush tube for WC pans                     766001


                 232 Cistern-less WCs
