/ Frame systems for direct flush TEMPOFIX 3 with TEMPOFLUX 2

• Efficiency and water savings: direct flush reduces the risk of leaks, powerful and constantly available flush, 3L/6L dual flush
• Specifically designed for public and commercial places: space saving, easy to clean, withstands intensive use
• Easy to install: frame system delivered pre-mounted
• Hygiene: no cistern: no water stagnation (reduces bacterial development)

TEMPOFIX 3 with TEMPOFLUX 2
Frame system for drywall
• Self-supporting frame system with large feet to fix to load-bearing floors.
• Black powder-coated steel frame.
• Frame height can be adjusted from 0 - 200mm (with 1m mark).
• Ø 32mm flush tube with Ø 55mm connection washer.
• ABS soil pipe Ø 100mm outlet with waterproof seal,
with 2 setting positions.
• Delivered pre-mounted.
• For walls from 10 - 35mm.
Fitted with TEMPOFLUX 2 time flow direct flush system:
• Cistern-less flush system: directly connected to pipework.
• Ø 195mm chrome-plated metal wall plate with concealed fixings.
• Available with 6L single flush or 3L/6L dual flush
can be adjusted to 2L/4L.
• Soft-touch operation.
• Vacuum breaker.
• Stopcock and flow rate/volume adjuster.
• Solid brass body and shock-resistant, scale-resistant mechanism.
• In-line inlet M¾".
• Compatible with rain water.
• Acoustic level complies with European standard EN 12451 class II.
• 30-year warranty.

Ø 195 10-35
3/4"

1000-1320

TEMPOFIX 3 WC frame system with TEMPOFLUX 2 (for drywall from 10 - 35mm) 300-620
578305
3L/6L dual flush (DELABIE patented)
+ 578222
180-230 165
578305
6L single flush (can be adjusted to 9L) 350 157-177
+ 578212
For Ø 90mm (or 110mm) soil pipe outlet versions: add "BE" (or "DE")
after the reference for kit 1
Options: wall fixings, sleeve connector and kit for disabled WC (see page 233)
578305 + 578222
