BINOPTIC 2 electronic tap
Ref. 383000
Mains, for slim panels, stopcock, L. 140mm
Mains, for slim panels, stopcock, L. 140mm
DESCRIPTION
BINOPTIC 2 electronic tap
Ref. 383000
Product currently under development.
Satin finish electronic basin tap for slim panels:
230/6V mains supply.
Reduced-stagnation solenoid valve and electronic unit are integrated into the body of the tap.
Flow rate pre-set at 3 lpm at 3 bar, can be adjusted from 1.4 - 6 lpm.
Scale-resistant aerator.
Adjustable duty flush (pre-set flush ~60 seconds every 24 hours after last use).
Wall-mounted stainless steel tap.
Presence detection sensor at the end of the spout optimises detection.
Anti-blocking security.
Spout with smooth interior and low water volume (reduces bacterial development).
Set detection distance, duty flush and launch thermal shocks manually.
Suitable for people with reduced mobility.
30-year warranty.
230/6V mains supply.
Reduced-stagnation solenoid valve and electronic unit are integrated into the body of the tap.
Flow rate pre-set at 3 lpm at 3 bar, can be adjusted from 1.4 - 6 lpm.
Scale-resistant aerator.
Adjustable duty flush (pre-set flush ~60 seconds every 24 hours after last use).
Wall-mounted stainless steel tap.
Presence detection sensor at the end of the spout optimises detection.
Anti-blocking security.
Spout with smooth interior and low water volume (reduces bacterial development).
Set detection distance, duty flush and launch thermal shocks manually.
Suitable for people with reduced mobility.
30-year warranty.
ADVANTAGES

Exceptional water savings: 90%

Hygiene: no manual contact

Anti-bacterial proliferation duty flush

LED diagnostic aids
TECHNICAL CHARACTERISTICS
BINOPTIC 2 electronic tap
Ref. 383000| Supply | 230/6V mains supply |
| Connector | M½" |
| Technology | Electronic |
| Spout length | 140mm |
| Flow rate | 3 lpm |
| Finish | Satin |
| Certificates |
|
| Warranty | |
VARIANTS
| 382010 | Chrome-plated: L.220mm, M1/2" connection, stopcocks, cross wall | ||
|---|---|---|---|
| 38201015 | Chrome-plated: L.220mm, Ø 15mm compression fittings, cross wall | ||
| 381110 | Chrome-plated: L.140mm, M1/2" connection, cross wall | ||
| 383010 | Chrome-plated: L.140mm, M1/2" connection, stopcocks, for slim panels | ||
| 381010 | Chrome-plated: L.140mm, stopcocks, for cross wall installation | ||
| 38101015 | Chrome-plated: L.140mm, Ø 15mm compression fittings, cross wall | ||
| 382110 | Chrome-plated: L.220mm, M1/2" connection, cross wall | ||
| 384110 | Chrome-plated: L.220mm, M1/2" connection, recessed | ||
| 384110E | Chrome finish: L. 220 mm, Bluetooth connectivity, M1/2", recessed | ||
| 384100 | Satin finish: L. 220mm, M1/2", recessed |
